APNX V1-W Panoramic Dual-Chamber Mid-Tower Case – White/Wood | V1-W-WT-v1
The APNX V1-W White/Wood (V1-W-WT-v1) is a premium panoramic dual-chamber mid-tower case featuring a distinctive solid ash wood accent, full tempered-glass showcase design, and unique 45° angular airflow intake. It supports ATX motherboards, GPUs up to 395mm, CPU coolers up to 170mm, up to 10 fans, and multiple 360mm radiators for high-performance gaming builds.
Product Overview
The APNX V1-W White/Wood combines the performance-focused architecture of the V1 with a premium natural-wood accent. APNX officially identifies this White/Wood configuration as V1-W-WT-v1, featuring solid ash wood with a protective finish to complement the white chassis and panoramic tempered-glass appearance.
Its distinctive 45° angular intake design directs fresh air toward the main components while maintaining a wide panoramic view of the system. The angled cooling position accommodates 3 × 120mm, 2 × 140mm, or 2 × 160mm fans, providing substantial airflow for high-performance CPU and GPU configurations.
A key feature is the two-position adjustable motherboard mounting mechanism. The motherboard can be repositioned to prioritize additional GPU airflow or provide more room for thicker radiator-and-fan combinations when CPU liquid cooling is the priority.
The V1 supports up to 10 fan positions, with cooling locations at the front-right, top, bottom, and rear. Liquid-cooling support extends to 360mm radiators at the front-right, top, and bottom, plus a 120mm rear radiator. APNX notes that certain bottom radiator configurations depend on motherboard position and does not generally recommend bottom-mounted liquid cooling.
Hardware compatibility includes ATX, Micro-ATX, and Mini-ITX motherboards, graphics cards up to 395mm when no radiator is installed at the front-right, CPU air coolers up to 170mm, and ATX power supplies up to 220mm including cables. An adjustable GPU support mount is included for large graphics cards.
The dual-chamber layout provides a generous 90mm internal cable-management depth with dedicated routing channels, Velcro ties, and rubber pathways. Storage configurations support up to 2 × 3.5-inch drives plus 4 × 2.5-inch SSDs, or as many as 6 × 2.5-inch SSDs.
Please check the official manufacturer website for the latest and most accurate compatibility, clearance, radiator, fan, and I/O specifications before purchase or finalizing a build.
Key Features
- 🤍🌳 White/Wood Edition – V1-W-WT-v1
- 🌳 Premium Solid Ash Wood Accent with Protective Finish
- 🪟 Full Panoramic Tempered-Glass Design
- 🖥️ Dual-Chamber Mid-Tower Layout
- 🌬️ Unique 45° Angular Air Intake
- 🔄 Two-Position Adjustable Motherboard Mount
- 🔲 ATX / Micro-ATX / Mini-ITX Support
- 🎮 Up to 395mm GPU Clearance
- 🛡️ Adjustable GPU Support Mount Included
- ❄️ Up to 170mm CPU Cooler Height
- 🌀 Supports Up to 10 Fans
- 🌀 Supports Up to 2 × 160mm Fans
- 💧 Up to 360mm Front-Right Radiator
- 💧 Up to 360mm Top Radiator
- 💧 Up to 360mm Bottom Radiator
- ⚡ ATX PSU up to 220mm Including Cables
- 💾 Up to 6 × 2.5" SSDs
- 🧰 90mm Cable-Management Depth
- 🔧 Quick-Release Cooling Brackets & Panels
- 🧹 Built-In & Removable Dust Filters
- 🔌 USB 3.2 Gen 2×2 Type-C 20Gbps
- 🔌 2 × USB 3.2 Gen 1 Type-A
- 🎮 Optional PCIe 5.0 Vertical GPU Kit
Technical Specifications
| Category | Cases |
| Manufacturer | APNX |
| Model | V1-W-WT-v1 |
| Case Type | Mid-Tower PC Case |
| Motherboard Support | ATX / Micro-ATX / Mini-ITX |
| GPU Clearance | Please Check Official Specifications |
| Radiator Support | Please Check Official Specifications |
| Included Fans | None |
| Front I/O | 1 × USB 3.2 Gen 2×2 Type-C / 2 × USB 3.2 Gen 1 Type-A / Audio & Mic |
| PSU | ATX, up to 220mm including cables |
| Color | White |
| Warranty | 1 Year Manufacturer Warranty |
